Hapfo 5000-H Copy Lathes
Technical Specifications
| Model | Hapfo 5000-H |
|---|---|
| Max ø over bed | 260 mm |
| Weight | 400 – 550 kg |
| Overall Length | 2250 / 2550 / 3450 mm |
| Overall W x H | 450 mm / 1230 mm |
| Spindle Taper | 450 mm / 1230 mm |
| Tailstock Taper | 2 mt |
| Spindle Thread | M33 x 3.5 mm |
| Power | 400V, 3-phase |
| Speed | 40–910 rpm / 80–2000 rpm / 140–3500 rpm |
Available Configurations
Code
Description
01500APHA
Wood-copying lathe hapfo 5000-H
400 Volts, 3 phases, 50 Hz, N, PE
Distance between centres 1400 mm / copying length 1250 mm
with manual advance (without follower rests), including 1 HSS tool.
400 Volts, 3 phases, 50 Hz, N, PE
Distance between centres 1400 mm / copying length 1250 mm
with manual advance (without follower rests), including 1 HSS tool.
01510APHA
Wood-copying lathe hapfo 5000-H
400 Volts, 3 phases, 50 Hz, N, PE
Distance between centres 1700 mm / copying length 1550 mm
with manual advance (without follower rests), including 1 HSS tool.
400 Volts, 3 phases, 50 Hz, N, PE
Distance between centres 1700 mm / copying length 1550 mm
with manual advance (without follower rests), including 1 HSS tool.
01520APHA
Wood-copying lathe hapfo 5000-H
400 Volts, 3 phases, 50 Hz, N, PE
Distance between centres 2600 mm / copying length 2450 mm
with manual advance (without follower rests), including 1 HSS tool.
400 Volts, 3 phases, 50 Hz, N, PE
Distance between centres 2600 mm / copying length 2450 mm
with manual advance (without follower rests), including 1 HSS tool.
All prices exclude VAT. View all woodturning CNC and Copy Lathes
